Core, Select, Reserve. One matching system.
The same window or door, offered in three performance levels, so a semi-custom home, a custom home and a certified project can all come off one schedule from one supplier.
Core
Built to hit the budget on semi-custom homes and upscale multifamily: thermally broken 6063-T5 aluminum, Low-E argon glass, and prescriptive energy code met in Climate Zone 2.
- U-factor
- 0.37 – 0.40
- SHGC
- 0.22 – 0.25
- Hardware
- CMECH
- Warranty
- 10 yrs · hardware 3
- Rating
- Manufacturer values
Select
Our most popular collection for custom homes: tempered glass, T40 Low-E, a polyamide thermal break and Roto locking with Coastal 316 stainless handles. Arches, rakes and radius heads without the special-order delay.
- U-factor
- 0.30 – 0.39
- SHGC
- 0.20 – 0.25
- Hardware
- Roto + Coastal
- Warranty
- 10 yrs · finish 12
- Rating
- Manufacturer values
Reserve
For jobs that need a listed NFRC rating at plan check. Reserve Title 24 is triple glazed for Title 24 performance; Reserve Southwest covers Texas, Arizona, Nevada, New Mexico and Utah.
- U · Title 24
- 0.22 – 0.28
- U · Southwest
- 0.27 – 0.37
- SHGC
- 0.18 – 0.23
- Hardware
- Roto + Coastal
- Warranty
- 10 yrs · finish 15–20
Ranges cover the products in each collection; per-product figures are on each product page.
Side by side, windows.
| Specification | Collection 01Core | Collection 02Select | Collection 03Reserve Southwest | Collection 03Reserve Title 24 |
|---|---|---|---|---|
| Thermal break | Polyamide strut | Polyamide strut | Technoform polyamide | Technoform polyamide |
| Aluminum | 6063-T5 | 6063-T5 | 6063-T5 | 6063-T5 |
| Glazing | 5 + 20Ar + 5 Low-E | 6 + 12Ar + 6 Low-E | Double Low-E, argon | Triple 6 + 12Ar + 6 + 12Ar + 6 |
| Powder coat | AAMA 2604 Interpon · 2605 optional | AAMA 2604 Interpon · 2605 optional | AAMA 2604 Interpon · 2605 optional | AAMA 2604 Interpon · 2605 optional |
| Hardware | CMECH | Roto + Coastal 316 stainless | Roto + Coastal | Roto + Coastal |
| U-factor, fixed | 0.38 | 0.33 | 0.29 | 0.22 |
| U-factor, casement | 0.37 | 0.39 | 0.27 | 0.27 |
| U-factor, tilt & turn | — | — | 0.29 | 0.23 |
| SHGC | 0.22 – 0.25 | 0.20 – 0.25 | 0.19 – 0.20 | 0.18 – 0.22 |
| NFRC certified | No | No | Yes | Yes |
| Where it fits | Semi-custom homes, upscale multifamily | Custom homes | TX · AZ · NV · NM · UT | Title 24 performance |
Side by side, doors.
| Specification | Collection 01Core | Collection 02Select | Collection 03Reserve Southwest | Collection 03Reserve Title 24 |
|---|---|---|---|---|
| Glazing | 5 + 20Ar + 5 Low-E | 6 + 12Ar + 6 Low-E | Double Low-E, argon | Triple 6 + 12Ar + 6 + 12Ar + 6 |
| Threshold | Standard sill | Low and high options | Flush recessed | Flush recessed |
| U-factor, swing door | 0.39 | 0.37 | 0.33 | 0.24 |
| U-factor, sliding, 2 panel | 0.40 | 0.39 | 0.37 | 0.28 |
| SHGC | 0.22 – 0.23 | 0.21 – 0.22 | 0.19 – 0.21 | 0.19 – 0.23 |
| NFRC certified | No | No | Yes | Yes |
Core and Select figures are manufacturer whole-unit values and carry no NFRC listing. Reserve ratings are NFRC certified, and the certification number comes with your quote. Figures vary with opening size and glazing option.
Included, not upgraded.
These come on every unit in every collection, at no extra line on the quote.
Every pane on every unit is tempered, not only where the inspector requires it.
Low-E, argon-filled insulating units in every collection, Low-E on every opening.
Standard in Reserve, so no shiny bar shows at the edge of the glass.
Every opening unit locks at several points, with CMECH or Roto hardware.
Made to the millimeter, including arches, rakes and angled heads.
Nail fin setbacks of 7/8, 1 and 1-3/8 in to match your wall.
AkzoNobel Interpon AAMA 2604 powder coat; AAMA 2605 and dual-color frames at additional charge.
Every quote and shop drawing gives the unit size and the rough opening.
What's covered, and for how long.
One ARI limited warranty for all three collections. The collection on your order sets the term.
| Coverage | Core | Select | Reserve |
|---|---|---|---|
| Frame and welds | 10 years | 10 years | 10 years |
| Glass seal | 10 years | 10 years | 10 years |
| Finish — AAMA 2604 powder coat | 10 years | 12 years | 15–20 years* |
| Hardware and screen mechanisms | 3 years | 5 years | 10 years |
*Reserve’s finish is 15 years on the standard AAMA 2604 powder coat and 20 years where AAMA 2605 is specified at order, at an upcharge. Coastal salt corrosion is not covered on Core and is covered for 10 years on Reserve. The hardware term covers locks, handles, hinges, rollers, operators and screen mechanisms.
Labor is not covered. The care guide that ships with each order keeps the coverage in force: wash the frames a few times a year, keep the drainage slots clear, lubricate the hardware once a year and never paint over the powder coat. Water on the inside of the glass is room humidity, not a failed seal.
Price it both ways. Then decide.
Send the schedule and we will quote it in more than one collection, so you can see the difference line by line.
Request a Quote
